Ortofon Fonocaptor Ortofon MC Cadenza Black

Output voltage at 1000 Hz, 5cm/sec. - 0,33 mV Channel balance at 1 kHz - 27 dB Channel separation at 15 kHz - > 20 dB Frequency range at - 3dB - 20 - 60.000 Hz Frequency response 20 kHz - 20 kHz - +1,5/0 Tracking ability at 315Hz at recommended tracking force *) - 90 µm Compliance, dynamic, lateral - 16 µm/mN Stylus type - Nude Shibata on Boron cantilever Stylus tip radius - r/R 6/50 µm Tracking force range - 2,0-2,5 g (20-25 mN) Tracking force, recommended - 2,3 g (23 mN) *) Typical value Tracking angle - 20° Internal impedance, DC resistance - 5 Ohm Recommended load impedance - > 10 Ohm Cartridge body material - Stainless steel Aluminium Cartridge colour - Black/Black Cartridge weight - 10,7 gram The Cadenza Black model is using a   Nude Shibata stylus   with a boron cantilever. The effective mass of the stylus/cantilever system is extremely low due to the use of a very thin boron rod. This material is extremely stiff and even more lightweight than aluminium. It also uses the WRD/Wide Range Damping-system applied for MC Windfeld, MC A90, MC Anna, Xpression and MC A95 cartridges, controlling the high and low frequency damping separately. The coil wire is the famous Ortofon Aucurum wire, which is a gold plated 6NX copper wire. Cadenza Black is high performing on areas like detail, consistency and sound staging.   "...the Black uses many moving parts of the A90...sound is weighty and satisfyingly rhythmic...The Black offered a beautifully smooth, svelte and expansive sound stage. It has generous stage depth and always sounds relaxed and in control of proceedings... ...If you are looking for an ultimately smooth and sophisticated sonic delivery from LP, Ortofon's new Cadenza Black is as good as it gets at what is a 'reasonable' price...the Black is a lovely cartridge..."    At Ortofon we constantly look for new technology to be used in our products and push the performance of existing technology. Thus we assure the highest level of performance and
